Ceiling-mount WiFi 7 AP with 6 GHz support, 2.5 GbE uplink, and 9.3 Gbps over-the-air speed.
WiFi 7 with 6 GHz support
140 m² (1,500 ft²) coverage
300+ connected devices
Powered using PoE+
2.5 GbE uplink
Technical Specifications
Mechanical
Dimensions
Ø206 x 46 mm (Ø8.1 x 1.8″)
Weight
680 g (1.5 lb)
Enclosure materials
Polycarbonate, metal
Mount material
Mounting bracket: stainless steel (SUS304)
Backing plate: galvanized steel (SGCC)
Hardware
Networking interface
(1) 2.5 GbE RJ45 port
Management interface
Ethernet
Power method
PoE+
Power supply
UniFi PoE switch
Supported voltage range
44—57V DC
Max. power consumption
21W
Max. TX power
2.4 GHz
5 GHz
6 GHz
22 dBm
26 dBm
23 dBm
MIMO
2.4 GHz
5 GHz
6 GHz
2 x 2
2 x 2
2 x 2
Throughput rate
2.4 GHz
5 GHz
6 GHz
688 Mbps
2882 Mbps
5765 Mbps
Antenna gain
2.4 GHz
5 GHz
6 GHz
4
