Indoor/outdoor intercom terminal for managing residential and commercial building entry requests.
Unlock using an NFC card, UniFi Identity mobile app, PIN code or QR code
Directory and doorbell to request entry
Pairs with multiple UniFi Intercom Viewers for remote access control
Connects to UniFi Access Hub series using PoE
Weatherproof (outdoor exposed -30 to 60° C)
Technical Specifications
Mechanical
Dimensions
324.8 x 113.7 x 28.3 mm (12.8 x 4.5 x 1.1″)
Weight
Device: 965 g (2.1 lb)
Bracket: 445 g (1 lb)
Enclosure material
Aluminum alloy, UV-stabilized polycarbonate, glass
Mount material
Powder-coated stainless steel
Mounting
Wall mount, adapter to the gooseneck pedestal (Included)
Surface angle mount, flush mount (Optional)
Sunshield kit (Optional)
Weatherproofing
IP65
Hardware
Networking interface
(1) GbE RJ45 port
Connectivity
Bluetooth 4.2
NFC
Power method
PoE
Supported voltage range
48V DC
Max. powe
