? (5) Gigabit RJ45 ports with passive PoE support ? (1) Gigabit SFP port for backhaul applications ? Ports configurable for line-rate, Layer-2 switching ? 130 kpps for 64-byte packets ? 1 Gbps for 1518-byte packets Dimensions 142 x 75 x 23 mm (5.59 x 2.95 x 0.91″) Weight 215 g (7.58 oz) Max. Power Consumption 5W Max. Total PoE Output 50W @ 24V PoE Output Passive 24V (Pins 4, 5+; 7, 😎 Power Input 24VDC, 2.5A Power Adapter (Included) Power Supply External AC/DC Adapter Supported Voltage Range 9 to 26VDC Button Reset LED Power, Link/Activity (6), PoE (5) Processor Dual-Core 880 MHz, MIPS1004Kc System Memory 256 MB DDR3 RAM Code Storage 256 MB NAND Certifications CE, FCC, IC Wall-Mount Yes ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV Operating Temperature -10 to 45° C (14 to 113° F) Operating Humidity 10 to 90% Noncondensing Networking Interfaces Data/PoE Output Port (5) 10/100/1000 RJ45 Ports Data Port (1) 100/1000 SFP Port PoE with 24VDC Power Adapter PoE Out Voltage Range 22-24VDC Max. PoE Wattage Per Data/PoE Output Port 12W (24V) Max. PoE Wattage Combined (All 5 Data Ports) 50W PoE Method Passive
