Uninterruptible power management system designed to support high-capacity WISP deployment sites.
(3) Power TransPort outputs
Delivers up to 480W* (27V DC) to supported UISP devices
(2) PSU bays with (1) 250W AC/DC Power Supply included
(1) DC battery port for an external 24V lead-acid battery (not included)
Supports SMS-over-LTE (Cat M1) notification**
Compatible with UISP Console, UISP Router (installed with UISP Box), UISP Router Pro, UISP Switch (installed with UISP Box), UISP Switch Pro
*With (2) power supplies installed.
**Requires a nano-SIM card from a Cat M1 SMS provider.
Technical Specifications
Mechanical
Dimensions
442.4 x 267.5 x 43.7 mm (17.4 x 10.5 x 1.7″)
Weight
4.16 kg (9.2 lb)
Enclosure materials
SGCC steel, polycarbonate/ABS
Hardware
Networking interface
(1) 10/100 MbE RJ45 LAN port
Management interface
Ethernet In-Band
Bluetooth
Power TransPort interface
(3) Power TransPort ports [up to 250W (27V DC) output eac
