Ubiquiti airMAX AC 5 GHz, 21 dBi, 60º Sector

Support auf Maß
+ Installationservice
+ Managed Services

Ubiquiti airMAX AC 5 GHz, 21 dBi, 60º Sector

196,03  zzgl. USt

As the next generation of 2x2 MIMO sector antennas from Ubiquiti Networks, the airMAX® ac Sector Antennas feature significant advances in scalability, noise isolation, and beam performance to complement the Rocket?5ac radios. They are also compatible with RocketM5 models; however, optimal performance requires the Rocket5ac. Frequency Range 5.10 - 5.85 GHz Gain 21 dBi Mounting Universal Pole Mount, Rocket Bracket, and Weatherproof RF Jumpers Included --> Rocket M wird noch benötigt!

Möchtest du benachrichtigt werden, wenn dieses Produkt wieder auf Lager ist?

5 GHz, 60º, 21 dBi BaseStation sector antenna for Point-to-MultiPoint (PtMP) networks.

2x2 dual-polarity performance

Robust mechanical design for outdoor application use

Compatible with Rocket Prism 5AC

Technical Specifications

AM-5AC21-60
Dimensions
750 x 173 x 78 mm (29.5 x 6.8 x 3")
Weight
4.8 kg (10.6 lb)
Frequency Range
5.10 - 5.85 GHz
Gain
21 dBi
HPOL Beamwidth
60° (6 dBi)
VPOL Beamwidth
60° (6 dBi)
Electrical Beamwidth

Electrical Downtilt

Max. VSWR
1.5:1
Wind Survivability
200 km/h (125 mph)
Wind Loading
391 N @ 200 km/h (88 lbf @ 125 mph)
Polarization
Dual-Linear
Cross-pol Isolation
25 dB Min.
ETSI Specification
EN 302 326 DN2
Mounting
Universal Pole Mount, RocketM Bracket, and Weatherproof RF Jumpers Included

0/5 (0 Reviews)
Gewicht 6,250 kg
Größe 0,920 × 0,245 × 0,375 cm
