BaseStation that supports speeds of up to 150+ Mbps real TCP/IP throughput.
2.4 GHz frequency band
150+ Mbps throughput
Plug-and-play integration with airMAX antennas
Technical Specifications
Mechanical
Dimensions
160 x 80 x 30 mm (6.30 x 3.15 x 1.18")
Weight
500 g (1.1 lb)
Enclosure material
UV-stabilized plastic
Hardware
Networking interface
(1) 10/100 MbE RJ45 port
Power method
Passive PoE (pairs 4, 5+; 7, 8 return)
Power supply
24V, 0.5A PoE adapter (Included)
Max. power consumption
6.5W
RF connectors
(2) RP-SMA (waterproof)
Operating frequency
2402 - 2462 MHz
Shock and vibration
ETSI300-019-1.4
Operating temperature
-30 to 75° C (-22 to 167° F)
Operating humidity
5 to 95% noncondensing
Certifications
CE, FCC, IC
