A UniFi Network Console platform specifically designed for massive scale.
Manage 1000+ UniFi Network devices and 10,000+ clients
(1) 10G SFP+ and (1) GbE RJ45 LAN port
(2) 550W redundant power supply units (PSUs)
Full 1U form-factor
Bluetooth for instant setup
Technical Specifications
Mechanical
Dimensions
787 x 43.7 x 481.4 mm (31 x 1.7 x 19″)
Weight
13.1 kg (28.9 lb)
Enclosure materials
Front panel: aluminium
Chassis: SGCC steel
Mount material
SGCC steel
Hardware
Processor
16-core Intel® Xeon®-SP Gold 5218 at 2.3 GHz
Memory
(2) 16 GB DDR4 ECC RDIMM
On-board storage
(1) 256 GB, M.2 2280 SATA
Management interface
Ethernet
Bluetooth
Networking interface
(1) LAN: GbE RJ45 port
(1) MGMT LAN: GbE RJ45 port
SFP+ interface
(1) LAN: 10G SFP+ port
Power method
Universal AC input, 100—240V AC, 7A max, 50/60 Hz
Power supply
(2) Hot-swappable AC/DC PSU, 550W
LCM display
(1) 1.3″ touchscreen
Button
