Long-range, dual-band, 802.11ac Wave 1 access point with a 1.2+ Gbps aggregate throughput rate.
185 m² (2,000 ft²) coverage
250+ connected devices
WiFi 5 (3x3 MIMO)
Powered using PoE*
*PoE power adapter included with single unit purchases.
Technical Specifications
Mechanical
Dimensions
Ø175.7 x 43.2 mm (Ø6.9 x 1.7")
Weight
Without mount: 240 g (8.5 oz)
With mount: 315 g (11.1 oz)
Hardware
Networking interface
(1) GbE port
Management interface
Ethernet
Power method
PoE
24V passive PoE (Pairs 4, 5+; 7, 8 return)
Power supply
UniFi PoE switch
24V, 0.5A Gigabit PoE adapter**5-packs do not come with PoE adapters.
Max. power consumption
6.5W
Max.TX power
2 GHz
5 GHz
24 dBm
22 dBm
MIMO
2.4 GHz
5 GHz
3 x 3
2 x 2
Throughput rate
2.4 GHz
5 GHz
450 Mbps
867 Mbps
Antenna gain
2.4 GHz
5 GHz
3 dBi
3 dBi
Button
Factory reset
Mounting
Wall/ceiling (Included)
