5 GHz LTU client that functions in a point-to-multipoint (PtMP) environment with the LTU Rocket as its base station.
900+ Mbps throughput*
22 dBi high-gain antenna with InnerFeed® technology
Easily integrates with LBE 5AC Gen?2 deployments
Includes (5) feeds and (5) PoE adapters
*FW version 2.3.0 and later.
Technical Specifications
Mechanical
Dimensions
Feed: 201.46 x 64.15 x 56.15 mm (7.93 x 2.53 x 2.21")
Antenna: 358 x 271.95 x 288.5 mm (14.09 x 10.71 x 11.36")
Weight
Feed: 215 g (7.58 oz)
Antenna: 890 g (1.96 lb)
Antenna with mount: 1.07 kg (2.36 lb)
Enclosure material
UV-stabilized polycarbonate
Wind loading
275 N at 200 km/h (61.8 lbf at 125 mph)
Weatherproofing
IPX6
Hardware
Networking interface
(1) GbE RJ45 port
Power method
Passive PoE 2-pair (4, 5+; 7, 😎
Power supply
24V, 0.5A Gigabit PoE adapter (included)
Supported voltage range
22-26V DC
Max. power consumption
8.5W
RF connections
Interna
