POYNTING ANTENNAS Solutions

Poynting Antennas is a specialized manufacturer of RF antenna systems and accessories, engineering products for connectivity applications ranging from maritime deployments to fixed wireless installations. The Poynting product catalog combines LTE/5G MIMO arrays, Wi-Fi 6E/7 radios, and GPS/Glonass positioning within unified enclosures — an integration-first design approach that reduces cabling complexity at the deployment site.

Poynting antenna solutions target environments where signal reliability and physical durability are non-negotiable. Marine omni-directional models such as the A-OMNI-0904-V1-01 are rated for wind survival below 190 km/h, with an operating temperature range of -40°C to +80°C across the broader catalog. Connector options vary by SKU — N-Type for marine omni models, SMA variants for M2M/IoT form factors — allowing engineers to match antenna hardware to modem specifications without adapter chains.

ASCEND supplies Poynting antenna solutions as Peplink Authorized E-Tailer and Peplink Certified Gold Partner, alongside Ekahau Reseller Partner status — providing matched antenna-router configurations for Peplink and Teltonika deployments.

Poynting marine antennas are engineered with UV-stabilized and saltwater-protected enclosures specifically for sustained exposure to coastal and offshore environments. The SWIRL V1-02 integrates an innovative heat sink design for improved temperature regulation alongside UV and saltwater protection, allowing the enclosure to withstand prolonged maritime deployment without material degradation. The WaveHunter series (A-WHUNTER-001-V3-101 Poynting) provides 6x 4x4 MIMO LTE/5G, 4x4 MIMO Wi-Fi 6E, and 2x2 GPS/Glonass in an IP65-rated housing with RA-(RP)-SMA (m) connectors, consolidating three radio technologies into a single mast-mounted unit. The OMNI marine series extends the lineup with dedicated form factors: the A-OMNI-0494-V1-01 delivers 9.8 dBi gain across 2.4 GHz and 5 GHz as a 4x4 omni-directional marine antenna with a 2 m SMA (m) cable, while the A-OMNI-0914-V1-01 Uni-Direktionale offer N-Type connector variants for heavier-gauge RF cabling on larger vessels. Each marine SKU uses a white UV-resistant housing to minimize solar heat absorption and maintain RF performance under direct sun exposure.

Poynting 5G LTE MIMO antenna configurations scale from single-element 4x4 arrays to 6x 4x4 and 8x8 multi-element deployments, matching carrier-grade throughput requirements across fixed, mobile, and maritime installations. The A-RIPL-0016-V1-01 distributes four independent 4x4 MIMO LTE/5G paths across 16 SMA (F) connectors, enabling spatial diversity for sites where RF paths must be split across multiple modems or locations. The WaveHunter A-WHUNTER-001-V3-101 Poynting consolidate six 4x4 MIMO LTE/5G elements with 4x4 MIMO Wi-Fi 6E and 2x2 GPS/Glonass in a single IP65 housing. The SWIRL V1-02 pushes to 8x8 MIMO LTE/5G with WiFi 7 and GPS, covering the 617 to 6000 MHz band. For marine deployments requiring maximum physical resilience, the A-OMNI-0904-V1-01 carries IP68 water ingress protection with IK 10 impact resistance and MIL-STD 810G/ASTM B117 salt spray compliance, ensuring MIMO element integrity in offshore environments.

The A-EPNT-0004-V1-17 and A-OMNI-0298-V1-01 serve fixed outdoor installations where mast or wall mounting is required for elevated RF line-of-sight. The A-EPNT-0004-V1-17 is a white omni-directional 5G/LTE antenna with an SMA (F) connector, designed for permanent exterior deployment on building facades or poles. The A-OMNI-0298-V1-01 targets Wi-Fi coverage across 2.4 GHz and 5 GHz bands, shipping with a 2 m cable for direct routing into indoor networking equipment. Both Poynting mast wall antenna models share a white UV-resistant enclosure suitable for long-term weather exposure. Installers typically pair the A-EPNT-0004-V1-17 with cellular routers at remote sites where directional antennas are impractical due to multi-carrier or rotating signal sources. The A-OMNI-0298-V1-01 complements that cellular link by extending Wi-Fi distribution to outdoor areas or bridging building-to-building connections. POYNTING ANTENNAS positions both models for infrastructure-grade fixed wireless rather than mobile or temporary deployments.

Poynting antenna availability spans four distinct catalogue families: marine/coastal, 5G/LTE mast and wall, M2M/IoT, and Wi-Fi — each stocked with multiple connector variants to match router-side interfaces. The marine/coastal line alone includes the A-WHUNTER-001-V3-101, A-OMNI-0914-V1-01, A-OMNI-0904-V1-01, A-OMNI-0902-V1-01, and A-SWIRL-0008-V1-02, covering everything from compact omni-directional units to high-element-count MIMO arrays. Mast and wall models such as the A-EPNT-0004-V1-17 and A-OMNI-0298-V1-01 ship with SMA (F) and 2 m cable options respectively. M2M/IoT deployments draw from the A-OMNI-0600-V2-01 with its 5 m SMA-M cable. Ascend holds POYNTING ANTENNAS stock across these categories so integrators can source antennas, mounting hardware like the A-BRKT-063-V1-01 Uni-Direktionale Pedestal, and router bundles such as the Teltonika RUTC 50 paired with the A-MIMO-0004-V1-17 without waiting on separate supplier lead times.

Poynting marine antenna selection spans three tiers of offshore RF density and durability. The WaveHunter A-WHUNTER-001-V3 delivers the highest MIMO layer count in the marine/coastal catalogue: six independent 4x4 MIMO LTE/5G chains, 4x4 MIMO Wi-Fi 6E, and 2x2 GPS/Glonass consolidated in a single IP65 housing with RA-(RP)-SMA (m) connectors — targeting multi-modem vessel installations running concurrent carrier aggregation. For exposed deck and mast positions, the A-OMNI-0904-V1-01 uses N-Type (F) connectors and maintains IP68 ingress protection with MIL-STD 810G/ASTM B117 salt spray compliance at operating relative humidity up to 98%.

For carrier-grade 5G and fixed wireless access, POYNTING ANTENNAS offers two distinct deployment profiles. The A-EPNT-0004-V1-17 provides omnidirectional 5G/LTE coverage in a white mast/wall-mount enclosure with SMA (F) connectors, suited to single-access-point fixed wireless installations. The A-RIPL-0016-V1-01 targets high-density sites where multiple modems require parallel MIMO chains, featuring a dedicated path-to-ground connection for lightning protection and storage humidity tolerance from 5% to 95% non-condensing. Integrators select the A-EPNT-0004-V1-17 for mast-mounted perimeter coverage and the A-RIPL-0016-V1-01 for co-located multi-modem router installations, covering both single-point and high-density fixed wireless scenarios from the POYNTING ANTENNAS catalogue.

The A-OMNI-0600-V2-01 is POYNTING ANTENNAS' ultra-wide omnidirectional LTE antenna purpose-built for compact machine-to-machine installations where a single radome must cover the full 617–6000 MHz range. At 6.2 dBi peak gain, the A-OMNI-0600-V2-01 delivers enough link budget for IoT gateways mounted on vending machines, kiosks, or industrial controllers without requiring a high-gain directional dish. The antenna terminates in an SMA male connector on a 5 m cable, giving installers flexibility to route the feedline through tight enclosures to modem ports on Teltonika or Peplink routers. Its white UV-stable housing keeps the form factor unobtrusive on customer-facing equipment. This Poynting IoT antenna guide positions the A-OMNI-0600-V2-01 as the go-to choice when deployment space is constrained but frequency coverage must span legacy LTE bands through current 5G NR allocations.
