ASCEND Case Studies: Projects That Hold Up Under Load

A ski jumper in mid-flight, a store talking to the head office's merchandise system in Hockenheim, 1,000 viewers watching a livestream: in each of these moments everything depends on a connection that must not drop. Since 2010, Ascend of Nuremberg has been building networks that hold exactly when it matters. Here we show how Krämer Pferdesport, MDR, GEMA, the Olympiahalle and H2Fly worked with us, with figures, hardware and what we learned along the way.

The principle at a glance

The principle behind the ASCEND case studies: several internet connections, Peplink SpeedFusion bonds them and switches over on failure, resulting in one stable connection that Ascend monitors around the clock

Four of the five projects follow the same pattern: every site, vehicle and ground station gets several paths to the internet, a Peplink router bonds them into one connection via SpeedFusion, and if one path fails, traffic continues over the remaining ones. At the Olympiahalle, by contrast, the focus was Wi-Fi for 8,000 visitors. Ascend advises, selects the hardware, implements it and then supports the systems around the clock for existing customers.

What our customers no longer experience since the project

The occasions were different, the problems behind them were not. These are the six risks we removed from day-to-day operations in the case study projects.

Dropped sessions when switching lines

Hot Failover switches over at packet level. The connection to the merchandise system or the streaming server stays up even when a line drops out.

One line as a single point of failure

Several connections from different providers are bonded. At GEMA this meant six LTE connections from three carriers plus one wired line.

Distributed sites without a stable corporate network

Krämer Pferdesport has branches in Germany, Austria, France and Switzerland and connects them to the central corporate network via SpeedFusion. The setup is designed for 100 sites; four existing sites were connected after six months, and all 52 are to follow.

Stutter in the live picture

At GEMA, a line that had degraded was taken out of the transmission automatically and added back as soon as it was fit again, both without interruption.

Overloaded Wi-Fi in a full house

At the Olympiahalle, Ascend served 8,000 visitors, including interpreting audio via the Livevoice app at stable voice quality.

Nobody reachable when things go wrong

Our technicians keep supporting the systems after installation, around the clock for existing customers. Management is central, through Peplink InControl 2.

Five projects, one pattern

TaskAscend solutionResult
Krämer Pferdesport (retail)Connect branches in Germany, Austria, France and Switzerland so that all sites communicate without interruption with the head office in Hockenheim and the merchandise management system.Peplink Balance series routers with SpeedFusion, bonding of MPLS, LTE, DSL and fibre, Hot Failover, management via InControl as a virtual appliance; setup designed for 100 sites.Four existing sites connected in the first six months, all 52 sites planned. Design goal: communication with the merchandise management system without session drops when switching lines.
MDR (broadcasting)Protect outside broadcasts of sports, politics and concerts against connection faults and add line backup to existing WAN connections.Balance 710, MAX HD4 LTE-A and MAX Transit Duo LTE-A, InControl 2 on an existing VMware server.All available bandwidth bonded, reliable data transfer when sending live footage.
GEMA (members' meeting 2020)Virtual assembly for 80,000 members with up to 1,000 simultaneous viewers, where for legal reasons nothing was allowed to stutter.Two Balance 710 with two switches as a high-availability pair, six LTE connections from three providers plus cable, three floors covered, together with LanWorX.Uninterrupted transmission via an external streaming server.
Olympiahalle Munich (event)Seamless internet connection for an event with 8,000 visitors on 3 June 2023, with real-time interpreting via the Livevoice app (partner Blomen GmbH) for the first time.High-performance Wi-Fi network installed by Ascend in the Olympiahalle; participants heard the translation via Livevoice.Internet connection throughout the whole event, stable voice quality praised by the participants.
H2Fly (aviation)Reliably get telemetry data from the Hy4 hydrogen aircraft to the ground station during flight.MAX HD4 on the aircraft, Balance 380 on the ground, several LTE connections to a VPN hub in the Ascend data centre, GPS tracking.Telemetry despite fluctuating bandwidth, the prototype's position in real time on the map.

Branch networking in retail: Krämer Pferdesport

Employee at the service counter of an equestrian mega store confirming a customer order, the screen shows a green tick, saddles and shelves in the background

Krämer Pferdesport, an equestrian retailer with branches in Germany, Austria, France and Switzerland, develops, distributes and sells over 25,000 items for horse riding. With more than 900 employees, the company supplies over 800,000 customers in Germany, Austria, Luxembourg, France, the Netherlands, Belgium and, through its subsidiary Felix Bühler, in Switzerland. Around one million orders a year are processed through the online shop, and there are Mega Stores of about 1,300 square metres of sales space each in the DACH region and in France.

The requirement was clear: employees at all sites must communicate without interruption over the corporate network, with the head office in Hockenheim and the merchandise management system, so that enquiries, orders and payments are processed promptly. Krämer had evaluated solutions from Barracuda, Fortigate and Viprinet and chose the Balance series from Peplink, advised by Ascend and the distributor Vitel. The routers bond MPLS, LTE, DSL and fibre into one WAN connection via SpeedFusion. Every packet is encrypted individually, connection faults are detected and traffic continues at packet level over the remaining paths.

To be honest, not everything worked first time: during rollout there were errors with the OSPF routing protocol. The experts solved them quickly. The design relies on Hot Failover so that no session drops when a line switches. The setup was designed for 100 sites from the start: in the first six months four existing sites were connected, and in the long run all 52 sites are to follow. You can read the full case study at Patented SD-WAN technology at Krämer Pferdesport; how we connect sites in general is described on the page Site networking.

Outside broadcast without interruption: MDR

Mitteldeutscher Rundfunk broadcasts sports events, political events and concerts live. Even a short interruption is enough to miss a ski jumper's winning jump. The broadcaster therefore looked for an additional router solution specifically for outside broadcasts that adds line backup to existing WAN connections and provides transmission capacity independent of cable connections.

After consulting with Ascend and Vitel, MDR chose the Balance 710, MAX HD4 LTE-A and MAX Transit Duo LTE-A from Peplink (press release of 6 May 2020). With them the broadcaster bonds all available bandwidth and ensures reliable data transfer. Device management runs through InControl 2, installed on an existing VMware server at the broadcaster. Another goal was a central bonding solution for the whole MDR group: the subsidiaries are to operate and administer their own routers in future, via the multi-tenant platform InControl 2.

The models chosen back then have since been replaced by successors, but the principle has stayed the same: the MAX HD4 became the MAX HD4 MBX, the MAX Transit Duo became the MAX Transit Duo Pro. You can find the full report at MDR: interruption-free outside broadcast with SD-WAN; the technology behind it is explained on our SD-WAN page.

Streaming and events: GEMA and Olympiahalle

At GEMA's virtual members' meeting in 2020 there were 80,000 members and up to 1,000 simultaneous viewers, and for legal reasons nothing was allowed to stutter. Together with LanWorX, Ascend supplied three floors of the GEMA headquarters with a multiply redundant internet connection: two Peplink Balance 710 with two switches as a high-availability pair, connected to six LTE connections from three providers and one wired connection. The stream went to an external server and was distributed from there. If a line degraded, it dropped out of the transmission automatically and came back as soon as it was fit again, both without interruption.

At the Olympiahalle in Munich, Ascend provided Wi-Fi on 3 June 2023 for an event with 8,000 visitors. The special feature: for the first time the interpreters worked via the Livevoice app from our partner Blomen GmbH, and participants heard the translation in real time on their own smartphones. Voice quality stayed stable throughout. Both reports: GEMA members' meeting 2020 and Wi-Fi at the Olympiahalle for 8,000 visitors. If you need a network for your event, you will find case-based kits and full service under Rent Wi-Fi for events.

Telemetry from the air: H2Fly

H2Fly is developing the four-seat hydrogen fuel-cell aircraft Hy4, a hybrid of PEM fuel cells for range and high-performance lithium batteries for take-off and climb. For the development team to observe the drivetrain in flight, the telemetry data has to reach the ground reliably, across changing mobile networks and fluctuating bandwidth.

In September 2020 Ascend deployed a Peplink MAX HD4 on the aircraft and a Balance 380 at the ground station. Both connect over several LTE connections to a VPN hub in the Ascend data centre, so data keeps flowing even when switching between mobile carriers. The MAX HD4 also supplies the GPS position, so the prototype can be seen on the map in real time. More in the post Part of the H2Fly project and on the technology on the page VPN hub hosting.

What connects the projects: Ascend delivered not just hardware but consulting, solution selection and on-site implementation. We collect further reports on our work under We in the press.

How a project with Ascend works

  1. 1
    Clarify the requirementWe talk about sites, applications and what must never fail, such as the merchandise system, a livestream or telemetry.
  2. 2
    Select hardwareTogether we choose routers, modems and access points from the Peplink Balance and MAX series and suitable connections from several providers.
  3. 3
    Pre-configureOur technicians set up SpeedFusion, VPN hub and InControl 2 in advance, so that on site everything only needs to be plugged in.
  4. 4
    InstallWe set up the system on site, in the OB van or in the hall, and test the failover under load.
  5. 5
    OperateAfter handover we keep supporting the system around the clock for existing customers, with central monitoring via InControl 2.

A note on figures and models

All figures on this page come from the linked case studies and press releases and describe the status at the time of each project (MDR May 2020, GEMA 2020, H2Fly September 2020, Olympiahalle June 2023; the Krämer case study gives no date). Some Peplink models from these projects have since been replaced by successors; the hardware below shows the devices of the same series that are available today.
